ISK Bearings | B2B Bearing Wholesale
* ISK bearing precision conforms to internationally recognized standards: ABEC、ISO 492, DIN 620, and JIS B1514.
| 6206 Bearing Dimensions | Deep Groove Ball Bearings | |
|---|---|
The covers of the 6206 bearing are mainly divided into three types, ZZ, 2RS and OPEN.
A 6206 deep groove ball bearing generally consists of an inner ring, an outer ring, a spherical rolling element and a cage.The orbital ditch is slightly larger than the radius of the steel ball.Due to the point contact between the ball and the track, the 6206 bearing can withstand the bidirectional axial load in addition to the radial load. It is generally used in pairs in the normal situation, to reduce the induced load causing the internal axial forces using radial load.
How to Measure Ball Bearing Sizes？
Usually, 6206 bearings are used on the automotive、industrial machinery、agricultural equipment…etc
6206 bearings play a critical role in the automotive industry, being used in engine systems, transmission systems, suspension systems, and steering systems, among other components. They ensure smooth operation and control of vehicles.
In the field of mechanical manufacturing, 6206 bearings are widely used in equipment such as presses, pumps, gearboxes, and fans, ensuring stable operation and high performance of machinery.
Additionally, 6206 bearings are commonly found in various power tools such as electric drills, power screwdrivers, and angle grinders, enabling high-speed and precise operations. In the agricultural equipment sector, 6206 bearings are applied in tractors, harvesters, irrigation systems, and more, capable of handling demanding work environments and heavy load requirements.
The 6206 bearing has a 30 mm bore (d), 62 mm outer diameter (D) and 16 mm width (B). It is a single-row deep groove ball bearing. Confirm final selection against your actual operating conditions and drawing.
For the 6206 bearing, OPEN means no seal; Z/ZZ means a metal shield on one/both sides; RS/2RS means a rubber seal on one/both sides. Choose based on contamination, moisture and speed requirements.
The 6206 deep groove ball bearing carries both radial and bidirectional axial loads, suiting high speed and light-to-moderate loads. For heavy or special conditions, share your parameters for further evaluation.
6206 bearings are widely used in automotive drivetrains, industrial machinery (pumps, gearboxes, fans), power tools and agricultural equipment. Confirm suitability against your machine design.
Share the seal type, precision class, lubrication needs, annual volume and your application or drawing/sample. ISK Bearings can help evaluate the spec and quote integrated supply.
