The 6201 deep groove ball bearing is a common bearing model that is widely used in various machinery and equipment. In this article, we will delve into the dimensions of the 6201 bearing.
The 6201 bearing has a 12mm bore (inner diameter), a 32mm outer diameter, and a 10mm width.
Specifications| Inner diameter (mm), d | 12 |
|---|---|
| Outer diameter (mm), D | 32 |
| Width (mm), B | 10 |
| Inner diameter (inch), d | 0.4724 |
| Outer diameter (inch), D | 1.2598 |
| Width (inch), B | 0.3937 |
| Dynamic (kgf) | 535 |
| Static (kgf) | 305 |
| Weight (g) | 37 |
The inner diameter of the 6201 bearing is 12 millimeters. It can accommodate shafts with a diameter of 12 millimeters.
The outer diameter of the 6200bearing is 32 millimeters. This refers to the diameter of the outer ring of the bearing. Make sure that your application space can accommodate the outer diameter of the 6201 bearing.
The width of the 6201 bearing is 10 millimeters. This refers to the distance between the inner and outer rings of the bearing. Ensure that this dimension is suitable for your application to ensure proper installation and operation.
The 6201 bearing is a common and widely used bearing model. Understanding its inner diameter, outer diameter, and width dimensions is crucial for selecting the appropriate bearing. Based on your application requirements, load, speed, temperature, and quality criteria, choose the suitable size of the 6201 bearing for your application to ensure good performance and reliability.
The 6201 bearing is typically composed of an inner ring, outer ring, ball elements, and a cage. The groove in the raceway is slightly larger than the radius of the steel balls. Due to the point contact between the balls and the raceway, the 6201 bearing can withstand both axial loads in both directions and radial loads. It is commonly used in pairs under normal conditions to minimize the internal axial forces caused by the load and to primarily handle radial loads.
The inner ring serves as the primary raceway for the bearing's rotating elements.
Acting as the stationary raceway, the outer ring completes the race circuit and encapsulates the entire bearing.
These small, spherical elements provide the necessary separation and facilitate smooth rotation.
The cage holds the balls in place, ensuring equal distribution and preventing contact during operation.
Learn more: Radial Bearings: Types, Applications, Advantages, and Maintenance
The sealing covers for the 6201 bearing mainly come in three types: ZZ, 2RS, and OPEN.
6201 OPEN, 6201ZZ, and 6201 RS are different outer cover modes of the bearing. In this article, we will introduce these outer cover modes to help you choose the appropriate bearing protection method that suits your needs.
The 6201 OPEN type bearing cover is a design without a cover, allowing the internal components of the bearing to be exposed to the external environment. This design makes the bearing more susceptible to contamination from dirt, dust, and other external particles.
.jpg)
6201 ZZ refers to the 6201 bearing with metal shields as the outer cover. The metal shields effectively block dust, contaminants, and other external particles from entering while retaining the lubricant within the bearing.
.jpg)
6201 RS refers to the 6201 bearing with rubber seals as the outer cover. The rubber seals provide enhanced protection by effectively blocking moisture, dust, and other contaminants from entering. This sealing method is commonly used in harsh environments and applications that require stricter protection.
When choosing the appropriate bearing outer cover mode for your needs, consider the following factors:
Application environment: Determine the potential sources of contamination and other external particles in your application environment. Based on the environmental conditions, choose between open type, metal shields, or rubber seals to provide the appropriate protection.
Precision and speed requirements: Consider the precision and speed requirements of your application. Open type bearings are typically suitable for low precision and lower speed applications, while metal shields and rubber seals offer higher protection and are suitable for medium and high precision requirements.
Maintenance requirements: Consider your maintenance needs for the bearings. Open type bearings require regular cleaning and lubrication, while metal shields and rubber seals can reduce maintenance requirements.
6201 OPEN, 6201 ZZ, and 6201 RS are different outer cover modes of bearings that provide varying degrees of protection and support. Depending on your application environment, precision and speed requirements, as well as maintenance needs, choose the appropriate outer cover mode to ensure the normal operation of the bearing and extend its lifespan.
Standardized Size: The 6201 bearing is a standard-sized deep groove ball bearing that complies with international standard specifications, making it easy to select and replace.
High Load Capacity: Thanks to its deep groove ball structure, the 6201 bearing exhibits excellent load-carrying capacity, making it suitable for various applications.
High Speed: The internal design of the bearing allows the 6201 to achieve relatively high speeds, making it suitable for high-speed operating machinery.
Low Friction Loss: During operation, the 6201 bearing experiences low internal friction, leading to energy savings and reduced mechanical losses.
Strong Durability: With high-quality materials and precision manufacturing, the 6201 bearing boasts a longer service life, thereby reducing maintenance costs.
Wide Adaptability: The 6201 bearing finds extensive application in various mechanical equipment such as electric motors, gearboxes, automobiles, and agricultural machinery.
The 6201 bearing is a high-performance, durable, and reliable standard-sized deep groove ball bearing, suitable for various mechanical applications with different load and speed requirements.
.jpg)
Indicating the sealing or protection method of the bearing. "Z" represents metal shields, and "2Z" represents a bearing with two metal shields.
.jpg)
Indicating the sealing method of the bearing. "R" represents a bearing with a single rubber seal, while "2R" represents a bearing with two rubber seals.
The 6201 bearing is one of the bearings in the 6200 series and is also a commonly used model in multiple industries.
Below are the main industrial applications of the 6201 bearing:
The 6201 bearing plays a crucial role in the automotive industry. They are typically used in various components such as wheels, engines, transmissions, and steering systems. During the vehicle's operation, the 6201 bearing ensures smooth rotation of the wheels while bearing the loads and vibrations from the road surface.
The 6201 bearing is also widely used in various power tools, such as electric drills, grinders, and electric wrenches. These tools require stability during high-speed operation, and the 6201 bearing provides reliable support, ensuring smooth operation of the tools.
Similar to the 6200 bearing, the 6201 bearing is also widely used in household appliances, such as washing machines, fans, and mixers. These household appliances require long periods of operation, and the 6201 bearing ensures their stability and reliability.
The agricultural machinery sector is also one of the application areas for the 6201 bearing. They play a crucial role in providing support and connection in agricultural equipment, such as tractors, plows, and other farming machinery.
The 6201 bearing is widely used in various industrial machinery, such as pumps, fans, and gearboxes. These machines typically need to withstand high loads and high-speed operation, and the characteristics of the 6201 bearing can meet these requirements.
The 6201 bearing is a versatile and widely used bearing model. Its reliability, stability, and excellent performance make it the preferred choice of bearings in many different industries.
Learn more:
6200 Bearing Dimensions | Deep Groove Ball Bearings
6205 Bearing Dimensions：Your Ultimate Guide to Sizing
The 6201 deep groove ball bearing has a 12 mm bore (inner diameter), 32 mm outer diameter and 10 mm width, weighs about 37 g, and has a dynamic load rating of 535 kgf and static load rating of 305 kgf. These are ISO-standard dimensions suitable for direct replacement. Final selection should still be confirmed against your shaft size, mounting space and load conditions.
In the 6201 bearing designation, "6" indicates a single-row deep groove ball bearing, "2" the light series, and "01" a 12 mm bore. Suffixes indicate the closure type: Z or 2Z for metal shields (single/double side), R or 2R for rubber seals (single/double side). Reading the code correctly helps you match the right spec when replacing or requesting a quote.
The 6201 bearing comes in three main closures: ZZ (metal shield), 2RS (rubber seal) and OPEN. ZZ blocks dust and retains grease, suiting general medium-to-high precision applications; 2RS offers better water and dust resistance for harsh environments; OPEN has no closure, suiting clean settings or those needing regular cleaning and relubrication. Choose based on environment, precision/speed and maintenance needs.
The main differences between the 6201 and 6202 are outer diameter, width and load capacity. The 6201 has a 12 mm bore, 32 mm OD and 10 mm width; the 6202 has a 15 mm bore, 35 mm OD and 11 mm width, with higher load ratings. Start with your shaft diameter, then match mounting space and load. If you are unsure which fits your duty, share shaft size and load data for evaluation.
A noisy or rough-running 6201 bearing does not always mean the bearing itself has failed. In practice the root cause often lies in the press-fit condition, mounting concentricity, grease selection or contamination from the operating environment. Check the mounting and lubrication first before deciding to change the type. Share the running sound, mounting conditions and duty description, and we can help assess the cause.
If your 6201 bearing operates in damp, wet or dusty conditions, the 2RS rubber-sealed version is worth prioritising, as it offers better water and dust resistance than the ZZ metal shield. For more severe environments or specific corrosion concerns, material and grease pairing can also be evaluated. Share your operating environment and duty so we can help identify the most suitable seal and protection combination.
The service life of a 6201 bearing is mainly affected by load, speed, lubrication, mounting accuracy and operating environment. Excessive load, insufficient lubrication, misalignment or contamination all accelerate wear. Selecting the right closure and grease and ensuring correct mounting help maintain stable operation. To evaluate a suitable spec for a specific duty, share your load, speed and environment conditions.
